Circuits 2008

Circuits 2008: New Features and Enhancements

The new version of Circuits 2008 software brings a number of new features and enhancements that make designing electronic and logic circuits easier and more enjoyable.

New Features:

- The ability to change the style of the point per terminal allows the user to choose whether to use a traditional cross or a blank circle for the terminals.

- A simple help to operate the program provides the user with basic information on how to use the program.

- The ability to crop out unused portions of an image when saving a circuit as an image to the clipboard or a file.

Enhancements:

- The ability to set the font style for individual labels allows the user to customize the appearance of the labels.

- The ability to save UNDO steps to a file allows the user to undo steps even after exiting the program.

- The ability to mark multiple objects using the mouse and marking rectangle makes it easier for the user to select multiple objects at once.

- Fixing an error when moving objects outside the drawing area boundaries prevents objects from being lost.

- Fixing an error when undoing steps using the CTRL Z key, especially for actions with multiple objects at once.

- Fixing an error when copying components to the clipboard using the CTRL C key.

- Fixed other minor bugs.

Other enhancements:

- MDI window support allows the user to open multiple documents at once.

- The ability to select multiple items at once and move or delete them in bulk makes it easier for the user to manipulate multiple items.

- Minor changes throughout the application improve the overall look and usability of the program.

- Significantly faster application startup.
